Cisco 8200 Series Switch
(8202-32FH-M)
The Cisco 8202-32FH-M, a robust 2RU chassis, offers enhanced performance with 32x400G ports, fortified by XR Software, HBM, and MACsec. It is ideal for high-demand enterprise networks, providing exceptional data handling capabilities for seamless operations.
8202-32FH-M Specifications
| Model | 8202-32FH-M |
|---|---|
| Chassis Size | 2RU |
| Ports | 32x 400G |
| Software | XR Software |
| High Bandwidth Memory (HBM) | Yes |
| MACsec Support | Yes |
| Switching Capacity | Up to 12.8 Tbps |
| Forwarding Rate | Up to 6.4 Bpps |
| Power Supply | Dual Redundant Power Supply |
| Cooling System | Front-to-Back Airflow |
| Management | CLI, GUI, SNMP |
| Latency | < 1??s |
| Buffer Size | Deep Packet Buffers |
| Dimensions (HxWxD) | 3.45 in x 17.5 in x 21.5 in |
| Operating Environment | Commercial |
| Operating Temperature | -5??C to 40??C |
| Relative Humidity | 5% to 90% non-condensing |
| IEEE Standards | 802.3ad, 802.1p, 802.1Q |
| Security Features | ACLs, Secure Boot, Role-Based Access Control |
