Cisco Catalyst 9200L Switch (C9200L-48P-4X-A)
The C9200L-48P-4X-A is a Cisco Catalyst 9200L fixed-uplink access switch with 48 full PoE+ 10/100/1000 copper ports and 4 fixed 1/10G uplinks. With Network Advantage software, StackWise-80 support, and 740W of available PoE power with one PWR-C5-1KWAC power supply, it is designed for campus, branch, and wiring-closet access deployments that need 10G uplink capacity.
C9200L-48P-4X-A specification
| Model | C9200L-48P-4X-A |
|---|---|
| Brand | Cisco |
| Product Description | Catalyst 9200L 48-port PoE+ 4x1G uplink Switch, Network Essentials |
| Product Type | Fixed-uplink managed access switch |
| License Tier | Network Advantage |
| Downlink Ports | 48 × 10/100/1000 PoE+ RJ-45 ports |
| Fixed Uplink Ports | 4 × 1/10G SFP+ fixed uplink ports |
| Uplink Module Support | Supports 1G SFP and 10G SFP+ transceiver modules according to the applicable Cisco compatibility matrix and software version. |
| Switching Capacity | 176 Gbps/td> | Switching Capacity with Stacking | 256 Gbps |
| Forwarding Rate | 130.95 Mpps |
| Forwarding Rate with Stacking | 190 Mpps |
| Flow Entries | Up to 16,000 flow entries for 48-port models |
| Stacking Technology | StackWise-80 |
| VLAN Standard | IEEE 802.1Q |
| Chassis Dimensions (H × W × D) | 1.73 × 17.5 × 11.3 in. (4.4 × 44.5 × 28.8 cm) |
| Chassis Dimensions with Fans and Power Supplies Installed (H × W × D) | 1.73 × 17.5 × 12.9 in. (4.4 × 44.5 × 32.9 cm) |
| Storage Temperature | –40 to 158°F (–40 to 70°C) |
| Relative Humidity | 5% to 90%, noncondensing |
| Operating Altitude | Up to 10,000 ft (3000 m) |
